HINO DX2. DPF reset function

For work DPFoff on any HINO trucks after remap (sometimes before) need make DPF reset function via HINO DX2 software. Its Windows App, work via J2534, and very stable with Scanmatik 2.

For HINO 2008 SH7058 choose:

  1. Clear DTC function “Delete all”. Need make it when no DTC too.

2. Check Inspection Menu.

  • “Start Inspection”
  • Make “Reset all DPR items”
  • Check “DPR abnormal overheat flag” = ON
  • “End Inspection”

3. System protection data. Check flags and make “Reset” via button. See now value = OFF

4. Recheck result in Inspection


This changes was in EEPROM ECU. Scaner change it. But if some problem with scaner can CLEAR direct from EEPROM dump, but often need 4-5 versions testing.

Posted on

Kubota Red Lamp, Not Start, Beeper solved

Hello colleguas! We have developed Stage1 SCR/DEF DPF EGR off solutions for 90% types kubota engines.

Many tractors and other machines with kubota engine often has problem with SCR DPF EGR components. For example DPF problems:

Screen from service manual Kubota. DPF you can download here:

Diagnosctic manual Kubota V3800.pdf

DPF system has 3 types fill status:

  • Level 1 – Green. DPF filter is filled above 26000mg, regeneration will occur automatically if there are suitable engine modes during tractor operation. The driver is not notified, it is expressed only through diagnostics with the error code DTC P3006
  • Level 2- Yellow. DPF filter is filled above 31000mg, forced regeneration is urgently required. The DTC code is P3007. It is turned by driver compartment with a button, and the tractor will fry its diesel fuel for 0,5-3 hours. But how many owners of such equipment have read the manuals? And from those who read, did you forget to follow the hired drivers so that they regenerate the DPF filter? Therefore, the next level often comes.
  • Level 3 – Red. DPF filter is filled above 36000mg,  in the cabin beeper is ON, red DPF error lamp is ON. DTC P3008. Limited power and the tractor can’t use. What now? Replacement of the diesel particulate filter with original new serial number (~4000$) and reset from the Kubota dealer scanner.

At this moment we can solve all types. Need make remap ECU and sometimes DCU (SCR unit).

Kubota ECU – DENSO can be GEN1 SH7058(1mb)/SH7059(1.5mb) and GEN2 SH72xxx(2mb) processors. Read/Write full dump and maps only via MMCFlash:

Also request EEPROM work. It makes via scaner with reset function or we make directly CLEAR EEPROM ECU dump from readed ORI EEPROM.

Posted on

BitBox 3.3.8 rev1

New modules:

  • Isuzu Transtron SH7058/SH7059/SH72533/SH72544 supports reading/writing and checksums calculation.

New families:

  • [EXCLUSIVE] Ford Continental EMS2701 TC1791 added to module Ford Continental Petrol CAN with virtual reading/writing and checksums calculation.

Improvements and fixes:

  • [EXCLUSIVE] Bosch MG1CA094 with SPC572 added to module Bosch MD1/MG1 Bench with reading/writing/recovery/checksums calculation and EEPROM reading.
  • Some stability fixes for SIM2K-260 on SM2 devices.
  • Added support for Mazda Mitsubishi Gen4 M41 ECUs.

Download page

Posted on

Happy New Year!

We congratulate you, dear colleagues, on the upcoming new year!

It has been a long, not simple and very eventful year. We have developed a lot of good things for you 🙂 But next year will be even better – we known!

For your joy, we have prepared new year’s discounts coupons:

Bit15% – Discount 15% for all modules BitBox/BitEdit |till 31.12.20

PCM10% – Discount 10% for all modules PCMFlash |till 28.12.20

MMC10% – Discount 10% for all modules MMCFlash |till 05.01.21

Files20% – Discount 20% for all files from our store! HOT! |till 05.01.21

Posted on

Instruction PCMFlash Module 64 – Mitsubishi Fuso Canter

Foreword about EDC7C4-6/EDC16C31:

1) It’s the same thing, it’s actually an EDC7 in an EDC16 case. Euro 3 and 4 toxicity standards. In these ECUs, SOFTWARE updates were not initially planned at all. In the first cars of 2007 (?) year (right hand drive), the bootloader area does not contain programs for this mode of operation. Trucks of the next years of production already contain everything needed, but it is implemented on a residual basis, apparently no one was going to use it. And they don’t use it. Here is for work with this curvature and was made module.

2) ECUs are of two types: only K-line (OBD plug has k-line and works identification and diagnostics) and CAN (OBD plug has CAN and k-line, but k-line NOT connected to ECU). All CAN ECUs also support k-line reprog, but of course, when directly connected to the ECU.

3) Can ECUs – the most unpleasant in the work, because there reprog is made crooked, so that the speed of the CAN-BUS does not coincide with the working speed. Therefore, if the truck is equipped with a tachograph or a robotic gearbox (perhaps something else), programming on the CAN-BUS in the truck will not be POSSIBLE. In this case, you will get an error when entering programming mode, and the ECU will “stop communicating”. In fact, everything is fine with it, if you unplug and connect back the battery terminal, it will “return”. To program such blocks, you will need to remove it and connect it directly to the ECU (can or K-line). Solution: after turning on the ignition, pause for 30 seconds before pressing OK.

4) All 24V units on the table normally work from 12V. Tactrix Open Port 2.0 does not formally support working at a voltage of 24 V, but You can do this at your own risk, provided that the truck will not start, and the battery is slightly low…

5) PCMFlash read from these ECU full dump! In the file will external and internal flash. Writing also full dump! Warning.

Pinout EDC7/16:

blue-GND, red-+12v, green-K-line, yellow-CAN-H, light blue-CAN-L

About EDC17. Read only the maps area. Recording – depending on the file, if it is possible to record the entire software, PCMFlash will ask about it. You can use files read in BSL. There are no special features for working with these ECUs

Pinout EDC17CP15:

You should not count the mod file checksum! The most common problem with EDC16 is recalculating compatibility checksum for writing via BDM.

Posted on

Instruction PCMFlash Module 58 – VAG DSG/CVT

Module 58, designed to work with the ECU, DSG and CVT. It supports writing on ” OBD ” (the main purpose – tuning), as well as work in BOOT mode (the main purpose – repair) – read and write memory of the processor, as well as external eeprom. For BOOT mode, a direct connection to the gearbox connector is used, but without opening the ECU. OBD work is supported for UDS variants of ECU

DQ200 (0AM) [WR/CK]
DQ250C (02E) [RD/WR/CK]
DQ250E/F (02E) [WR/CK]
DQ200MQB/G2 (0CW) [WR/CK]
DQ250MQB (0D9) [WR/CK]
VL300/V30 (01J/0AN) [WR/CK]
VL381 (0AW) [WR/CK]
DL501/G2 (0B5) [WR/CK]
DQ500 (0BH/0BT) [RD/WR/CK] reading when using a direct connection.

DQ200/MQB/G2 Boot (MICRO) [RD/WR/CK]
DQ200/MQB/G2 Boot (EEPROM) [RD/WR]
VL381 Boot (MICRO) [RD/WR/CK]
VL381 Boot (EEPROM) [RD/WR]
DL501/G2 Boot (MICRO) [RD/WR/CK]
DL501/G2 Boot (EEPROM) [RD/WR]

1) DQ200 – BOOT – all, OBD – all, except 0AM with K-line
2) DQ250 – BOOT – E/F/MQB, OBD – all
3) DQ500 – 0BT/0BH (no 0DL!) only OBD reading when using a direct connection
4) VL300/V30 – BSL – all, OBD – all, except KW1281
5) VL381 – all
6) DL501 – all

Work on OBD: as usual with other packages, there are no features, in case of recording interruption, you can turn off the ignition, then just record. In the case of “bricking” unsuccessful you can rewrite in the BOOT.

Work BOOT: use a direct connection to the connector of the control UNIT, the switching power supply is carried out either manually or (recommended) by using the scheme of automatic power control, powered by L-line (same PowerBox or converted from KESS). In case of manual control, the entrance to the boot mode may not happen on the first attempt.

Read DQ500: only when connected directly! NOTE: the power supply must be switched manually, while only the ignition must be switched on or off (pin 15), the second contact must be connected constantly!

Operation in BSL with VL300 / V30: requires drilling a single hole in the minimum diameter cap in order to insert a needle into it. Needle through a resistor 1 kOhm is connected to the mass. It is mandatory to connect to-line and it is highly recommended to use auto power to quickly “feel” the pin on the Board. The photos below show the drilling location and the point on the Board where the needle should go.



Wiring diagram for the connectors:

Red – +12в, Black – GND, Yellow – CAN-HIGH, Blue – CAN-LOW, Green – K-Line.

Cloning procedure-read MICRO and EEPROM from “old” box, write MICRO and EEPROM to “new”.

Below is a simple scheme for the organization of auto-feeding and work on the table. Need termination resistor at CAN bus!
